TP-LINK SX3016F Omada 16-Port 10GE SFP+ L2+ Managed Switch
เพิ่มเมื่อ: 2022-08-18 17:04:53.0
แก้ไขล่าสุด: 2025-05-03 16:14:36.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comSWITCH (สวิตซ์) TP-LINK SX3016F Omada 16-Port 10GE SFP+ L2+ Managed Switch, 16× 10G SFP+ Slots, RJ45/Micro-USB Console Port
TP-LINK SX3016F
SWITCH (สวิตซ์) TP-LINK SX3016F Omada 16-Port 10GE SFP+ L2+ Managed Switch, 16× 10G SFP+ Slots, RJ45/Micro-USB Console Port
- 16× 10 Gbps SFP+ slots
- 320 Gbps switching capacity
- Two power supply modules back each other up
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
- ERPS supports rapid protection and recovery in a ring topology
- Durable metal casing and rack-mountable design
Interface :
• 16× 10G SFP+ Slots
• 1× RJ45 Console Port
• 1× Micro-USB Console Port
Fan Quantity : 1
Physical Security Lock : √
Power Supply :
• Dual Redundant Power Supplies
• 100-240 V AC~50/60 Hz
Dimensions ( W x D x H ) : 17.3×8.7×1.7 in (440×220×44 mm)
Mounting : Rack Mountable
Max. Power Consumption : 32.74 W (220 V / 50 Hz)
Max Heat Dissipation : 111.71 BTU/hr (220 V / 50 Hz)
Switching Capacity : 320 Gbps
Packet Forwarding Rate : 238.08 Mpps
MAC Address Table : 32 K
Packet Buffer Memory : 24 Mbit
Jumbo Frame : 9 KB
Omada App Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access : Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning : Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features :
• Web-based GUI
• Command Line Interface (CLI) through the console port, telnet
• SNMP v1/v2c/v3: Trap/Inform, RMON (1,2,3,9 groups)
• SDM Template
• DHCP/BOOTP Client
• 802.1ab LLDP/LLDP-MED
• DHCP Auto Install
• Dual Image, Dual Configuration
• CPU Monitoring
• Cable Diagnostics
• Password Recovery
• SNTP
• System Log
Package Content :
• SX3016F Switch
• 2× Power Cords
• Quick Installation Guide
• Rackmount Kit
• Rubber Feet
System Requirements : Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
